Outdoor Optical Fiber and Power Hybrid Cable

Variable in-line optical attenuators,also know as adjustable in-line optical attenuator or short as VOA, are used to permit dynamic control of optical power levels in a fiber. It can be applied to adjust power level of signal in the optical communication at the output of light sources, E/O converters and for the linear or dynamic range of power meter. Furthermore, they can the used in optical amplifier systems to balance the gain across the different operating wavelengths.

The pulling eye can further speed up the installation process compared with filed termination. It saves time during installation of conduits, ducts or risers. In addition, the pulling eye protects the connectors of the trunk cables and prevents the cables from twisting during the installation process. Since the pulling eye is strain relived directly onto the outer jacket.With the pulling eye,the tension strength of the cables can reach up to 245N.

The 250μm fibers are positioned in a high modulus plastic loose tube.The tubes are filled with a water-resistant filling compound,wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The outer sheath can be PE or custom.

Fiber Optic Attenuator is one kind of optical passive device which is used to debug the performance of the optical power in the optical communication system,debugging fiber optic instrument calibration correction, optical signal attenuation.And used for the attenuation of the input optical power, avoid optical receiver distortion due to input optical power powerful. The fixed fiber optic attenuator can achieve the dual function of adapter and attenuators.

1000BASE-LH SFP 1310nm 40km DOM LC SMF Transceiver Module is designed for use in 100GBASE Ethernet and 4x28G OTN client interfaces throughput up to 40km over single mode fiber(SMF) using a wavelength of 1310nm via duplex LC connectors. Taking BOX+FPC+PCBA separate design, it has great reliability, airtightness and heat dissipation performance. This transceiver is compliant with IEEE 802.3ba 100GBASE-LR4 and OTU4 4I1-9D1F standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as 100G Ethernet, 112G OTN OTU4, telecom, service provider applications and 5G wireless network.

FBT coupler is a type of optical power management device that is fabricated using Fused Biconical Tape technology.It features small size, high reliability, cheap cost and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting.SZOPT provides a whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE.Both tree and star type inline couplers/splitters are available.Our items provide a reliable solution to split/combine signals.Single,dual,and tripple wavelength windows(1310/1490/1550nm) are available.

Fiber Optical Pigtail SC/FC/LC/ST/MU/E2000 12C 24C 48C 96C 144C has connectors on one end,with PVC,LSZH,OFNP jacket in yellow(SM);orange(OM1/OM2),aqua(OM3), magenta(OM4),lime green(OM5) or custom,the cable diameter can be custom,etc.

SZOPT’s MPO/ MTP loopback is a device widely used for parallel connection tests and an aging test of optical communication equipment. Our MPO/MTP loopback adapter can transmit the optical network signal from the transmitter to the receiver, thereby forming the optical signal receiving and transmitting loop. MPO/MTP loopback provides a fast and efficient way to test the transmission capacity and receiving sensitivity of optical network equipment. The MPO/MTP loopback has 8F, 12F, 16F, 24F, 32F channels with low loss, singlemode and multimode(OM1/OM2/OM3/OM4/OM5) options.

Adapter type fixed attenuator is the female to female fixed fiber optic attenuator,whichutilizes the air gap between two connectors to achieve the optical attenuation. Fixed adapter type attenuator is simple, low-cost and compact. It is recommended for use where return loss is not a concern nor is absolute attenuation value.

MPO MTP Trunk Cable Double Jacket can be available for 12Core 24Core 48Core or custom,such double jacket trunk cable is of much more rigid performance for preferable deployment of high density backbone cabling in data centers and other high fiber environment, reducing network in stallation or reconfiguration time and cost.MTP/MPO are used to interconnect cassettes, panels, or fan outs using a compact and rugged microcables structre. The micro cable optimizes cable way use and improve airflow.These MPO/MTP cable are build with the highest quality components , better insertion loss versions are offered accordingly,please contact SZOPT for details.

SZOPT’s 19” 1U/2U/3U/4U fiber swing out patch panel are SC/FC/ST/LC port available ,12C/24C/48C/96C/144C/288C fibers with the cold rolled steel powder well coated,designed to fit standard 19” racks. These patch panels are ideal for high density LAN interconnect or cross-connect patching,providing a designated terminus for interrelated cabling deployments.

SZOPT’s passive copper cable solutions provide power-efficient replacement for active power connectivity such as fiber optic cables. The SFP SFP+ QSFP+ QSFP28 cables provide 1Gb 40Gb 100Gb systems the ability to connect to switches or adapter cards. Optimizing systems to operate with passive copper cables significantly reduce power consumption and enlarge the connectivity opportunities of the system.
